Features

Flow capability 1500 l/min with inlet pressure of 10 bar. Maximum allowable back pressure is 9 bar. Lightweight hard coat anodized aluminum material for maximum resistance to corrosion and wear. 64mm (2.5" NH ) full-time swivel rocker lug inlet coupling and 64mm (2.5" NH ) rigid male outlet is standard.

Specifications

Flow Rate 1500 l/min
Inlet 2.5" (65 mm)
Inlet Coupling Style Rocker
Inlet Coupling Swivel Non-Full Time Swivel
Outlet 2.5" (65 mm)
Outlet Coupling Style Male Threads
Outlet Coupling Swivel Rigid
Pressure 150 psi (10bar)
Weight 15.2
